Beam Splitter Penta Prisms
  • Beam Splitter Penta PrismsBeam Splitter Penta Prisms

Beam Splitter Penta Prisms

Our Beam Splitter Penta Prisms products are popular in the market. Coupletech offers Beamsplitter Penta Prisms, which is one kind of Optical Elements. By adding a wedge and with partial reflective coating on first reflective surface, Optical prisms Beam splitter Penta Prisms can be used as Beamsplitter. We supply Beamsplitter Penta Prism with wedge and standard Transmission/reflection (T/R) ratio of 20/80, 50/50. Other T/R ratio is available upon request. Except Polarizing Beam Splitter Penta Prisms, Coupletech also offers Corner Cube Retro-Reflectors have three mutually perpendicular surfaces and a hypotenuse face.

Send Inquiry

Product Description

Beam Splitter Penta Prisms




Product Attributes


Brand:
Coupletech
Material:
BK7 Grade A Optical Glass
Dimension Tolerance:
±0.2 Mm
90°, 180Deviation Tolerance:
<10 Arc Seconds(High Precision)
Surface Quality:
60/40 Scratch/dig
Beamsplitter Ratio Transmission/Reflecti:
20/80± 5%/50±[email protected], T/R
Coating:
Upon Customer’s Request
Flatness:
λ/4 @ 633nm ( High Precision )



Supply Ability & Additional Information


Packaging:
Carton Packing
Productivity:
2000 pcs per year
Transportation:
Air
Place of Origin:
China
HS Code:
9002909090
Payment Type:
T/T
Incoterm:
FOB,CFR,CIF,FCA
Delivery Time:
35 Days





Packaging & Delivery


Selling Units:Bag/Bags

Package Type:Carton Packing





Coupletech offers Beamsplitter Penta Prisms, which is one kind of Optical Elements. By adding a wedge and with partial reflective coating on first reflective surface, Optical prisms Beam splitter Penta Prisms can be used as Beamsplitter. We supply Beamsplitter Penta Prism with wedge and standard Transmission/reflection (T/R) ratio of 20/80, 50/50. Other T/R ratio is available upon request. Except Polarizing Beam Splitter Penta Prisms, Coupletech also offers Corner Cube Retro-Reflectors have three mutually perpendicular surfaces and a hypotenuse face.

Corner Cube Retro-reflectors operates on the principle of total internal reflection (TIR). A beam entering the effective aperture is reflected by the three roof surfaces and emerges from the entrance/exit surface parallel to itself. This property is independent of orientation of the retro-reflector, within acceptance angle limitations. For applications in which either the acceptance angle for TIR is exceeded, or the reflecting surfaces can not be kept sufficiently clean for TIR, a metal or dielectric coating can be applied to the reflecting surfaces.



Looking for ideal Beamsplitter Penta Prisms Manufacturer & supplier ? We have a wide selection at goods prices to help you get creative. All the Beamsplitter Penta Prism with Wedge are quality guaranteed. We are China Origin Factory of Beamsplitter Cube Retro-Reflectors. If you have any question, please feel free to contact us.
