Wollaston Prism Polarizers Quartz
  • Wollaston Prism Polarizers QuartzWollaston Prism Polarizers Quartz

Wollaston Prism Polarizers Quartz

Our Wollaston Prism Polarizers Quartz products are popular in the market. Wollaston Prism Polarizer is made of two Birefringent materials prisms ( e.g. birefringent crystal materials: YVO4, a-BBO, Quartz, Calcite ) that are cemented together. It is an excellent kind of Polarizing Optic. The deviations of the ordinary and extraordinary beams are nearly symmetrical about the input beam axis, so that Wollaston Polarizing Beam Splitter has approximately twice the deviation of the Rochon. The separation angle exhibits chromatic dispersion, as shown in the blow. Any separation angle can be designed upon the requirement. The separation angle of standard products versus wavelength is shown in the plot below. Moreover, Coupletech aslo pruduce other kind of Laser Component, such as Pockels Cell Driver, Optical Element, Polarization Optics.

Send Inquiry

Product Description

Wollaston Prism Polarizers Quartz


Product Attributes


Brand:
COUPLETECH
Surface Quality:
20-10
Damage Threshold:
>500 MW/cm2
Material:
A-BBO, Calcite, YVO4, Quartz
Beam Deviation:
< 3 Arc Minutes
Coating:
Single MgF2
Extinction Ratio:
Calcite, Quartz:<5x10-5; A-BBO, YVO4:<5x10-6
Wavefront Distortion:
L/[email protected]
Parallelism:
<1 Arc Minutes
Mount: Bla
ck Anodized Aluminm 25.4mm
Wavelength Range:
A-BBO:190-3500nm,Calcite:350-2300nm,YVO4:400-700nm



Supply Ability & Additional Information


Packaging:
Carton packaging
Productivity:
1000 pcs per year
Transportation:
Air
Place of Origin:
China
HS Code:
9001909090
Payment Type:
T/T
Incoterm:
FOB,CFR,CIF,FCA,CPT
Delivery Time:
30 Days


Packaging & Delivery


Selling Units:Bag/Bags

Package Type:Carton packaging


Wollaston Prism Polarizer is made of two Birefringent materials prisms ( e.g. birefringent crystal materials: YVO4, a-BBO, Quartz, Calcite ) that are cemented together. It is an excellent kind of Polarizing Optic. The deviations of the ordinary and extraordinary beams are nearly symmetrical about the input beam axis, so that Wollaston Polarizing Beam Splitter has approximately twice the deviation of the Rochon. The separation angle exhibits chromatic dispersion, as shown in the blow. Any separation angle can be designed upon the requirement. The separation angle of standard products versus wavelength is shown in the plot below. Moreover, Coupletech aslo pruduce other kind of Laser Component, such as Pockels Cell Driver, Optical Element, Polarization Optics.
Wollaston Polarizer has advantages of very wide wavelength range, low power application, broadband 10000 : 1 extinction ratio, both ordinary and extraordinary beams are deviated, besides, it suits for low power application and where the large deviation is required.



Looking for ideal Wollaston Polarizers Prism Manufacturer & supplier ? We have a wide selection at goods prices to help you get creative. All the Wollaston Polarizers Quartz are quality guaranteed. We are China Origin Factory of Wollaston Prism Polarizers. If you have any question, please feel free to contact us.
